Ultra Fine Vertical Roller Mill

Introduction

We are a leading China-based manufacturer of Ultra Fine Vertical Roller Mill. Our mill is designed to meet the high demand for ultra-fine grinding of minerals, chemicals, and construction materials. Our product has numerous advantages that can meet the needs of merchants globally, making it the perfect choice for wholesalers and retailers alike.

Our Ultra Fine Vertical Roller Mill is superior to other brands as it provides superior quality, with our advanced technology and certification. Our product has been extensively tested and evaluated to meet the set standards of regional and international requirements.

Key Features of Ultra Fine Vertical Roller Mill

Efficient Grinding Performance

Our Ultra Fine Vertical Roller Mill is engineered to provide high-efficiency grinding performance. It uses advanced technology to create fine grinding without the risk of over-grinding. This milling machine is capable of achieving ultra-fine grinding of materials, providing better yield and quality.

Customizable Grinding Rollers

Our Ultra Fine Vertical Roller Mill comes with customizable grinding rollers, which give merchants the flexibility to enhance the grinding process of their desired products. The customer can change the size, material type, and pattern of the grinding rollers according to their product needs. The flexibility to customize the grinding rollers helps to obtain the desired product quality and consistency.

Easy to Use and Maintain

Our Ultra Fine Vertical Roller Mill is easy to use and maintain, reducing the overall cost of operation and maintenance. The product's intelligent design ensures that the machine can be operated seamlessly by the workers without requiring any extensive training.

Energy-Efficient Design

Our ultrafine machine is designed to consume less power, making it an energy-efficient piece of equipment. This feature not only saves on electricity bills but also comes with another advantage of environmentally-friendly milling. We believe that our product can help other manufacturers achieve their energy efficiency goals in their production processes.

Applications of Ultra Fine Vertical Roller Mill

Our Ultra Fine Vertical Roller Mill has numerous applications in various industries around the world. These include:

1. Building Materials: Our mill is widely used in the production of building materials such as cement, limestone, and gypsum. The machine provides high-quality construction materials that are durable and strong.

2. Chemicals: The mill is used to process various chemicals and minerals, such as talc, barite, and fluorite. Our machine produces high-quality chemical products that meet the needs of the chemical industry.

3. Pharmaceuticals: Our machine has several applications in the production of pharmaceutical products. The mill is widely used in the processing of minerals and chemicals used for medical purposes.

4. Food and Beverage: Our mill is also suitable for the production of food products, such as sugar, salt, and flour, as well as various beverages.

Conclusion

In conclusion, our Ultra Fine Vertical Roller Mill is an excellent choice for merchants worldwide looking for high-quality, energy-efficient equipment suitable for grinding various materials and applications worldwide. Our product has superior performance, is easy to use and maintain, and is engineered to meet regional and international standards. With our product, the merchants can have the flexibility to customize grinding rollers to meet their product needs. Thanks to our ultra-fine machine, merchants can have peace of mind that they can provide high-quality products that meet the needs of their customers globally.

Ultra fine vertical roller mill is a new type of ultra-fine powder making machine with high efficient and low cost features. It is designed based on the traditional Raymond mill.

The fineness of the finished product can be adjusted between 325-1250 mesh. It has the advantages of high efficiency, low energy consumption, environmental protection, small occupation area, low investment cost and so on.

1. Application field

It is widely used in metallurgy, mining, chemical industry, cement, construction, refractory materials and other industries.

2. Applicable materials

Limestone, calcite, talc, barite, dolomite and other non-metallic ores, non-flammable and explosive ores, non-corrosive brittle materials, granular and powdery raw materials.

1. The material falls on the grinding table through the screw feeder.

2. And the centrifugal force generated by the rotation of the grinding table driven by the reducer driven by the main motor makes the material to move evenly around the grinding table.

3. When the material passes through the roller table area on the grinding table, it is crushed by the grinding roller.

4. Large pieces of material are directly crushed, and smaller particles are squeezed to form a material bed for inter-particle crushing.

5. After being crushed, the material continues to move to the edge of the grinding disc, and is brought into the powder classifier by the airflow from the air inlet for classification.

6. Under the action of the blades of the powder classifier, the powder that does not meet the particle size requirements falls into the grinding disc for regrinding.

7. The powder that reaches the standard enters the pulse dust collector with the airflow through the powder separator for collection, and the collected and discharged powder is the finished product.

8. Impurities such as iron nuggets mixed in the material are difficult to grind and have high gravity. When they pass through the edge of the grinding disc, they cannot be taken away by the airflow and fall into the lower chamber of the mill. It is sent to the slag discharge port by the scraper and discharged out of the machine.

1. Excellent quality of finished product

Adopting the principle of vertical abrasive bed grinding, the material stays in the mill for a short time, reducing repeated grinding, so the product contains the least amount of iron, and the product has high whiteness and purity.
The powder content of the finished product with a particle size of less than 2 μm can reach 70%, achieving a low residue of 325 mesh, and can increase the secondary powder selection to select finer particle size finished products.

2. High grinding efficiency

The speed of the main engine adopts frequency conversion speed regulation, which is widely applicable to various materials. The specially designed roller sleeve and liner grinding curve makes it easier to form a material layer than ordinary vertical mills, and can grind to the required product fineness at one time.

The use of mechanical and electronic double limit protection devices effectively prevents the direct contact between the roller sleeve and the disc liner, and avoids destructive impact and severe vibration.

3. High level of environmental protection

Small vibration and low noise. The equipment is sealed as a whole, and works under negative pressure, no dust spills, the environment is clean, and the environmental protection requirements are higher than the national standard.

4. Good economic benefit

The principle of the multi-head powder separator, and each rotor adopts frequency conversion speed regulation, the fineness of the finished product can be realized within the selected range, and there is no need for secondary sorting, and there is no existence of inferior materials.

5. Low cost input

● Equipped with an automatic control system, it can realize remote control and is easy to operate.

● Adopting PLC/DCS automatic control of grinding roller pressure control mode, the grinding pressure is precisely controlled without manual operation.

● The grinding roller and the grinding disc are not in contact during work, and the grinding roller and the liner are made of high-quality materials, with less wear and long service life.

● The grinding roller can be pulled out to the outside of the casing for inspection and maintenance. It is convenient and quick to replace the roller sleeve and liner, reducing the loss of downtime.

● The grinding roller lubrication adopts a separate lubrication station, and a single grinding roller circuit adopts the mode of double pump-pump suction working at the same time, so that the grinding roller bearing can be fully lubricated and cooled, and it can avoid excessive oil in the grinding roller bearing chamber and leakage.
