80tph Mobile Stone Crusher

80tph Mobile Stone Crusher reduces the requirements of split components on-site infrastructure and the difficulty of installation of auxiliary facilities and can save a lot of capital construction and relocation costs. It can crush materials on site and move with the advance of raw material mining face, thus greatly reducing the transportation cost of materials. Truly provide customers with hardware facilities for efficient and low-cost project operation.

Send Inquiry

Product Introduction

Introduction of 80tph Mobile Stone Crusher

Production Capacity: 80 tph
Maximum Feeding Size: 550 x 300 mm
Feeding Height: 3.8 meters
Main Configuration: Primary Jaw Crusher + Secondary Cone Crusher + 3 Decks Screen
Total Motor Power: 220 kW
Electric Generator Requirement: 300 kVA
Weight of the plant: 44 Tonnes
Sizes of the plant: 116(L) x 3.2(W) x 4.2(L) meters
Chassis Type: Single chassis on wheels, equipped with hydraulic opening legs

Jaw Crusher With Feeder

Parameter 80tph Mobile Stone Crusher

Model	Feeding Size (mm)	Discharging Size (mm)	Capacity (t/h)	Power for Diesel engine (kw)
PE400×600	340	40-100	16-60	30
PE500×750	425	50-100	40-80	55
PE600×900	500	65-150	60-150	75
PE750×1060	630	80-180	150-300	110
PEX300×1300	250	20-90	10-65	75

Features 80tph Mobile Stone Crusher

The size of 80tph Mobile Stone Crusher Machine With Feeder is determined by the rectangular or square opening (feeding port) at the top of the jaws. The sheet below shows different gaps for coarse and fine crushing applications, PE Jaw Crusher (coarse crushing), and PEX Jaw Crusher (fine crushing).
